TM-30.0-S-4.0-DEMMR - Total Reflector Si 1.18" (30.0mm) Diameter, 0.160" (4.0mm) Thickness - For Co2 10.6um Laser Engraver/Cutter Machine

Turning Mirror: Si Ø30mm (1.18") x 4mm (.160")

APC PN: TM-30.0-S-4.0-DEMMR

Reference PN#:

Diameter: 30.0mm (1.18")

Thickness: 4.0 mm (0.160")

Product Specifications:

100% made in USA.

Anti-reflective coated focal lens for maximum 100W.

Focus lens is the fitting of CO2 Laser machine for engraving or cutting.

Type: Total Reflector Silicon (Si)

Material: Si - Silicon

Coating: 10.6um (AR Both Side)

Diameter Tolerance: 0/-0.13mm

Clear Aperture: >= 90% Diameter

Scratch/Dig: 40-20

Product color may be slightly different from the pictures.
